5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel

LG 55 inch 3.8mm patchwork,

LG Display LCD 550DUNTKB1 structural characteristics

Panel size: 55 inches

Backlight type: WLED

Point resolution: 1920 (RGB) x1080 (FHD) LG55 inch LCD splicing large screen model 550DUNTKB1 stitching 3.8mm

Aspect ratio: 16: 9 (width: height)

Pixel arrangement: RGB vertical bars

Pitch point spacing: 0.210x0.630mm (horizontal * vertical)

Pixel pitch: 0.630x0.630mm (horizontal * vertical)

Panel weight: 18.1 / 19.0kgs (Typ Max.)

Surface treatment: fog (Haze10%), Hard coating (3H)

Display area: 1209.6x680.4mm (horizontal * vertical)

Visible area: 1209.8x680.6mm (horizontal * vertical)

Appearance size: 1213.4x684.2mm (horizontal * vertical)

Appearance size: 34.6 / 60.4 (Typ Max.) Mm (thickness)

Landscape Portrait: Landscape Mode / Portrait Mode

Touch screen: None

LG Display LCD 550DUNTKB1 optical characteristics

Display mode: IPS, normally black display, transmissive

Panel brightness: 500cd㎡ (Typ.)

Contrast: 1400: 1 (Typ.) (Transmission)

Display color: 1.07B (10-bit)

Color saturation: 72% LG 55-inch LCD splicing large screen model 550DUNTKB1 stitching 3.8mm

Response time: 12 (Typ.) (G toG) (ms)

Viewing angle: 89/89/89/89 / (Min.) (CR≥10) (left / right / up / down)

Best viewing angle: symmetrical up, down, left and right

White chromaticity: X: 0.279; Y: 0.292

White field change: 1.11 / 1.25 (Typ Max.) (9points)

Scanning frequency: 60Hz

Reverse scan: No

Total power consumption: 160.3W (Typ.)

Packing box size: 1440x1140x950mm (length x width x height)

Tag: 55inch lcd video wall ; 5x5 lcd video wall ; narrow bezel lcd video wall

Our company is a private high-tech enterprise and owns intellectual property rights and national patent certificate for 80% of our products,Since the very beginning of our establishment,our company has been dedicated to the development and production of LCD products.

with the goal of "creating A New Era for Vison" and taking "quality-oriented and innovation-driven development"as philosophy,Our company has gradually grown into an industrial star with up to a hundred designs of products,including ultra-thin frame AD players,portable LCD AD players,AD player boxes,touch displays and LCD TV.The products have been widely used in relevant fields,making our company more powerful,infuential and highly favored in LCD production industry in China as well as in the world.Adhering to the pursuance of "high quality,reasonable cost and excellent service",Mercedes Technology is striving to become the most professional and excellent LCD monitor and HD AD player supplier in China.

Independently development brands: GEneVision--Create A New Era for Vision!

we have our own design, we design touchscreen kiosk for client, client can costomized the product according to the need. the ordering kiosk we design quality in high level, client sell a lot . we product high level quality with reasable price. work with out factory win win
